American Homebuilts

http://www.americanhomebuilts.com/homepage/

John Doe

Specifications

Construction

Airframe	Mig Welded 4130
Wing spars	6061-T-6 extruded I beam
Ribs	6061-T6 tube
Lift Struts	6061 extruded streamline

Cabin Area

Width	27"
Rear seat back to firewall	86"
Height	47"
Usable cargo area	18 cubic feet
Rear seat solo

Specifications

Gross Weight	1500 pounds
Fuel Cap	26 US gal.
Flap Extension	25º-40º
Aileron droop	10º-20º
Slat extension	2 1/8" lockable
Positive load	4.4 G's
Negative load	3.0 G's
Length	21'9" - spinner to tail with LOM
Wing span	30' 7"
Airfoil	N.A.C.A. 4415 - 51" cord
Wing area	130.55 square feet
Empty Weight	885 pounds

	Performance based on LOM-132-A  (utility catagory)

Engine	LOM-132-A
H.P.	120
Prop	LOM 72"-13"
Take off distance	120 ft.
Stall speed	30 mph.
Cruise speed	115 mph.
Dive speed	160 mph.
Clear 100' obstacle	600'
