CONSTRUCTION
|
COMPOSITE-FIBERGLASS, KEVLAR, CARBON FIBER
|
|
ENGINE
|
LYC, 0-320, 160 - 180 HP several
builders are experimenting with auto conversions.
|
|
CONTROL SURFACES
|
FOUR FLAPERONS
|
|
LANDING GEAR
|
RETRACTABLE - ELECTRIC/HYDRAULIC - ROUGH
TERRAIN
DUAL MAIN WHEELS
|
|
|
|
|
SPONSONS
|
SOLID CORE SHORT WINGS ATTACHED TO LOWER
FUSELAGE AT WATERLINE
|
|
LENGTH, HEIGHT
|
19.5 FEET, 7.5 FEET
|
|
WING SPAN
|
~27 FEET
|
|
WING LOADING
|
AT 1500# / 9.9LBS, AT 1800# / 11.92 LBS
|
|
PROPELLER
|
ALUMINUM HUB, 4 BLADE CARBON FIBER GROUND
ADJUSTABLE
|
|
CRUISE
|
140 MPH
|
|
VMAX,Vne
|
160 MPH
|
|
TAKEOFF ROLL
|
800ft.
|
|
LANDING
|
900ft
|
|
CLIMB
|
1200 fpm
|
|
STALL
|
50 CLEAN, 45 FULL FLAPS
|
|
EMPTY WEIGHT
|
~900# (Varies with Builder)
|
|
GROSS WEIGHT
|
1800#
|
|
USEFUL LOAD
|
900 POUNDS
|
|
FUEL CAPACITY
|
70 GAL
STANDARD (WET WINGS); 120
GAL MAX
|
|
RANGE
|
1100 Stat Miles +
|
|
SERVICE CEILING
|
12000 ft.
|
|
SEATING
|
2 PLACE SIDE BY SIDE - Cockpit 42"
Width
|
|
Kit Contents
|
Premolded Parts, SS Weldments, Additional
required foam and composite
materials, Landing gear, control system, AN hardware, wheels, tires, brakes
and full assembly instructions. Also a starter amount of glass and
epoxy.
|
|
Building Time
|
The factory staff builds a Goose in less
than 1000 Hours, with no special jigging
or equipment. Homebuilder times will vary depending on builder experience.
The many pre-molded parts, and composite construction, make the Goose a
'fast build' kit. To further cut time we offer several Quick Build Options. (see pricing.)
|
|
Kits Sold:
|
38
|
|
Complete Kit:
|
$29,500 US ( sub-kits are $10,000 each -
fuselage, tail, wings)
|
|
