Configuration
|
|
Airframe Name
|
CAPELLA XS TR
|
|
CAPELLA XLS TR
|
CAPELLA
XLS SUPER 100 TR
|
|
Airframe Model/'96 and up
|
FW2C65TR
|
|
FW2C80TR
|
FW2C100TR
|
|
Design takeoff weight
|
1100#'s
@ FAR Part 23 Utility Category Load Limits
|
|
Sport Pilot takeoff weight
|
1232#'s
@ New Sport Pilot Category Load Limits
|
|
Maximum structural takeoff weight
|
1270#'s
@ FAR Part 23 Normal Category Load Limits
|
|
Normal takeoff weight
|
925#s
|
|
1000#s
|
1100#s
|
|
Minimum empty weight
|
490#s
|
|
570#s
|
585#s
|
|
Wing span
|
28.5'
|
|
Wing chord
|
4'
|
|
Wing area
|
114 Sq. Ft.
|
|
Max wing loading
|
9.65#
per foot
|
|
Aspect ratio
|
7.13:1
|
|
Power loading
|
16.9
#/HP
|
|
13.9
#/HP
|
11.0#/HP
|
|
Max fuel capacity
|
22 US
Gallons (132#s)
|
|
Aircraft length
|
18'
5"
|
|
Aircraft height
|
5'
8"
|
|
Cockpit width @ Elbow Level
|
43"
(With doors Installed)
|
Greater
than 45"
|
|
Cockpit width @ Aft Door Sill
|
Greater
than 37"
|
39.5"
|
|
Cockpit width @ Fwd Door Sill
|
37"
|
39"
|
|
Cockpit
height
|
40"
|
|
|
|
|
|
|
|
|
|
|
Performance
|
|
Airframe Model
|
FW2C65TR
|
DESIGN SPEEDS
|
FW2C80TR
|
FW2C100TR
|
|
Performance
|
Dual
|
Solo*
|
calibrated
airspeed @ max. takeoff weight
|
Dual
|
Solo*
|
Dual
|
Solo*
|
|
Maximum speed at sea level
|
112mph
|
113mph
|
|
119mph
|
120mph
|
129mph
|
130mph
|
|
True Cruise Speed, 75% Pwr
@ 7K Ft
|
109mph
|
110mph
|
|
117mph
|
118mph
|
128mph
|
129mph
|
|
Stall speed (w/o flaps)
|
46mph
|
41mph
|
(52mph)
|
48mph
|
41mph
|
52mph
|
46mph
|
|
Stall speed w/flaps
|
39mph
|
36mph
|
(44mph)
|
40mph
|
38mph
|
44mph
|
39mph
|
|
Stall speed w/flaps pwr
on
|
37mph
|
34mph
|
|
38mph
|
36mph
|
40mph
|
37mph
|
|
Rate of climb at sea level
|
930fpm
|
1200fpm
|
|
1180fpm
|
1450fpm
|
1320fpm
|
1600fpm
|
|
Velocity never exceed
|
(140mph)
|
|
Max maneuvering
speed
|
96mph
|
87mph
|
(104mph)
|
100mph
|
90mph
|
104mph
|
96mph
|
|
Best angle of climb
|
55-65mph
|
|
Best rate of climb
|
60-80mph
|
|
Takeoff ground roll (min)
|
250ft
|
175ft
|
|
320ft
|
200ft
|
275'
|
180'
|
|
Landing ground roll
|
175ft
|
115ft
|
|
200ft
|
150ft
|
225'
|
175'
|
|
Service
Ceiling
|
10,000'
|
|
14,000'
|
16,000'
|
|
|
|
|
|
|
|
|
|
|
Powerplant
|
|
Airframe Model
|
FW2C65TR
|
|
FW2C80TR
|
FW2C100TR
|
|
Power Plant
|
Rotax 582
|
|
Rotax 912
|
Rotax 912S
|
|
Rated output
|
66hp
|
|
79hp
|
100hp
|
|
Displacement (CC)
|
580.7
|
|
1211.2
|
1611.2
|
|
Type
|
2-cycle
|
|
4-cycle
|
4-cycle
|
|
Propeller redrive
|
2.58:1,
3:1 optional
|
|
2.27:1
|
2.45:1
|
|
Fuel consumption (75% pwr)
|
4.8gph
|
|
3.5gph
|
4.2gph
|
|
Configuration
|
2
cylinder in-line
|
|
4
cylinder opposed
|
4
cylinder opposed
|
|
Ignition
|
dual mag CDI
|
|
dual mag CDI
|
dual mag CDI
|
|
Lubrication
|
oil
injection
|
|
dry
sump oil
|
dry
sump oil
|
